| Brand Name : | ES |
| Model Number : | ES-IPS507CH4WD |
| Certification : | CE, FCC |
| Delivery Time : | 3-5days after payment confirmed |
| Payment Terms : | T/T,western union,Paypal |
This Network video DVR is a network video server, support recording and capture picture. H.264 compression IP server,
can come with 7 cameras, including wired and wireless channel.
Product Function Introduction
· H.264 Compression IP camera server
· View/take picture by normal mobile phone
· 7 channel video, 4 channel audio
· Frame rate: CIF: 100fps, D1: 25fps
· Display, transfer and record under quad mode
· View by IE browser, no special software required
· Remote record and snapshot control via Internet
· Support motion detection, images can be sent out through alarm e-mails
· Support dynamic and static address
· RS485 PTZ controllable, multi channel alarm input and output
· History recording playback on remote PC
ES-IPS507CH4WD IP Camera Server Specification | ||||
Compression Standard | H.264 compression | |||
Image Resolution | PAL: D1(704x576) / CIF(352x288)/ QCIF (176x144) | |||
NTSC: VGA(640x480) / QVGA(320x240)/QQVGA(160x120) | ||||
Image Transfer Velocity | PAL: 1-25 frame/s, NTSC: 1-30frame/s | |||
Recording port | 1 channel USB2.0 port(main port) | |||
Bidirectional audio port | 1 channel USB2.0 port (subaltern port | |||
Video Input | 4 routes Wired channel, | |||
Video Output (local) | 1 route | |||
Audio Output (local) | 1 route | |||
Recording Standard | AVI | |||
PTZ Control Communicate Plug | RS485 | |||
Network Plugs | RJ-45/10-100 Base T | |||
Network Agreement | TCP/IP, UDP, ARP, HTTP, DHCP, FTP | |||
Motion Detection | user could set alarm area and sensibility | |||
Software Upgrade | upgrade automatically | |||
Monitor Mode | IE browser | |||
Video playback | VS Client | |||
Security | password setting: administer, monitor, scrutiny | |||
Working Condition | 0 ~ 50, 20% - 80%PH | |||
Power Adapter | INPUT: 100 - 240VAC, 50/60Hz, OUTPUT:5VDC/2A | |||
power consumption | < 5W | |||
Camera Specification | ||||
TV System | PAL | NTSC | ||
Validity Pixel | 512(H) x 582(V) | 512(H) x 492(V) | ||
Image Device | 1/4" sharp CCD | |||
Horizontal Definition | 420TV Line | |||
Minimum Illumination | 0Lux | |||
Transmission Signal | Video | |||
Working Temperature | -10℃~50℃ | |||
Syncronization System | Internal | |||
Scanning Frequency(H) | 15.625KHz | 15.734KHz | ||
Scanning Frequency(V) | 50Hz | 60Hz | ||
Backlight Compensation | Auto | |||
Electronic Shutter | 1/50(1/60)~1/100, 000sec | |||
White Balance | Auto | |||
S/N Ratio | >48db | |||
Gamma Correction | >0.45 | |||
Power Adapter | DC12V/500mA | |||
|
